SIRUBA 747 -FS MINI CYLINDER OVERLOCK MACHINE

Price 70000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Number

SIRUBA 747 -FS MINI CYLINDER OVERLOCK MACHINE Specification

Condition
Old

Warranty
yes

Stitch Formation
intertwining an upper needle thread with a lower thread or looper mechanism beneath the fabric.

Product Type
SIRUBA 747 FS MINI CYLINDER OVERLOCK MACHINE

Dimension (L*W*H)
58*45*50 Centimeter (cm)

Color
white

Stitch Length
3.8 mm and 4.5 mm Millimeter (mm)

Power
550 Watt (w)

Stitch width
4mm

Feed Mechanism
relies on an advanced Differential Drop Feed system

Voltage
220 Volt (v)

Sewing Speed
5,500

Sewing Thickness
5 mm to 9 mm

Needle
2

SIRUBA 747 -FS MINI CYLINDER OVERLOCK MACHINE Trade Information

Minimum Order Quantity
1 Number

Delivery Time
2 Days

About SIRUBA 747 -FS MINI CYLINDER OVERLOCK MACHINE

The SiRUBA 747 Cylinder Bed series (commonly designated under the 747KS or 747KST model lines) is a high-speed, industrial 4-thread overlock (serger) machine. It is specifically engineered with a small, circular sewing arm instead of a traditional flatbed. This design is purpose-built for sewing and edge-finishing small, tubular, or closed-loop garment sections.Â

Detailed breakdowns of this machine's key features, applications, and technical specifications are outlined below. [1]

Key Features

Mini Cylinder Bed Architecture: Features a narrow 148mm circumference bed. This allows small tubular pieces to slide smoothly over the arm without stretching or bunching. [1, 2, 3, 4, 5]
Direct-Drive Servo Motor: Most modern iterations come standard with an energy-efficient servo motor integrated directly onto the machine head. This setup reduces energy consumption by up to 75% compared to old clutch motors while minimizing noise and vibration.Â
Advanced Fabric Feeding: Equipped with an adjustable differential feed (ranging from 0.7 to 2.0). This prevents puckering on delicate fabrics and controls stretching on high-elastic materials.Â
Automatic Lubrication: A fully automatic, centralized oiling system ensures all internal moving components stay continuously lubricated for prolonged durability during high-volume production shifts.Â

Core Technical Specifications

Specification	Target Details
Stitch Formation	2-Needle, 4-Thread Overlock (Style 514)
Max Sewing Speed	Up to 5,000 to 6,500 Stitches Per Minute (SPM) depending on sub-model
Cylinder Circumference	148 mm
Max Stitch Length	Adjustable up to 3.8 mm 4 mm
Overedge Stitch Width	Standard 4 mm (total seam width up to 6 mm)
Needle System	DC27 (or B27)
Presser Foot Lift	Up to 5 mm

Primary Applications

The cylindrical arm makes this machine the industry standard for overedging circular items where flatbed machines cannot easily maneuver.

Attaching ribbed collars, necks, and cuffs on knitwear and T-shirts.
Seaming waistbands on leggings, underwear, activewear, and swimwear.
Hemming and closing pant legs, sleeve openings, and children's clothing.Â
