JIN M-1 OVERLOCK SEWING MACHINE

Name: JIN M-1 OVERLOCK SEWING MACHINE
Brand: NEWTECH MACHINERY
Price: 30000.0 INR
Availability: InStock

Price 30000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

JIN M-1 OVERLOCK SEWING MACHINE Specification

Product Type
JIN M-1 OVERLOCK SEWING MACHINE

Stitch Formation
the needle, the upper looper, and the lower looper.

Needle
DC 27 needle system

Dimension (L*W*H)
45 cm 30 cm 35 cm Centimeter (cm)

Stitch Length
0.8 mm up to 3.8 mm Millimeter (mm)

Power
550 Watts Watt (w)

Sewing Speed
6500

Color
off white

Warranty
yes

Feed Mechanism
bottom differential feed mechanism

Stitch width
4.0 mm and 6.0 mm,

Sewing Thickness
5 mm to 5.5 mm

Condition
Old

Voltage
220 Volt (v)

JIN M-1 OVERLOCK SEWING MACHINE Trade Information

Minimum Order Quantity
1 Number

Delivery Time
2 Days

About JIN M-1 OVERLOCK SEWING MACHINE

The JIN M-1 Series Overlock Sewing Machine is a direct-drive, high-speed industrial overlock and safety stitch machine manufactured by JUKI Corporation under their economical JIN (JUKI International) brand. Designed to deliver professional factory-quality edge finishes, this series combines high-speed output with lower power consumption by integrating the control box and operation panel directly into the machine head. [1, 2, 3, 4, 5]

Key Technical Specifications

The standard JIN M-1 series is engineered for high volume production environments: [1, 2]

Maximum Sewing Speed: Reaches up to 6,500 to 7,000 stitches per minute depending on the specific subclass variant.
Drive System: Energy-saving direct-drive servo motor (typically 550W) for minimal noise and lower vibration.
Fabric Responsiveness: Bottom differential-feed mechanism handles fabric thickness up to 5mm, adapting easily from light to heavy-weight materials with lower applied thread tension.
Stitch Adjustments: Supports a maximum stitch length of roughly 3.8mm to 4mm and a stitch width up to 6mm. [1, 2, 3, 4, 5, 6, 7]

Popular Subclass Models

The JIN M-1 lineup features distinct models engineered for different production requirements: [1, 2, 3, 4]

JIN M1-424NS: A standard 2-needle, 4-thread overlock machine designed for versatile, high-speed elastic seams on knitwear, t-shirts, and general garments. [1, 2]
JIN M1-534SF: A 2-needle, 5-thread safety stitch overlock machine equipped with an automatic chain cutter and a 3-point sensor thread trimmer that actively prevents the operator from accidentally cutting the fabric. [1, 2, 3, 4]

Core Benefits

Cost Efficiency: Positioned as an affordable alternative to premium JUKI models, it inherits JUKI's engineering standards but optimizes features for budget-conscious workshops. [1, 2, 3]
Space-Saving Design: Eliminates bulky under-table motors since the control module, panel, and motor are all built compactly into the machine head. [1, 2, 3]
Safety & Control: Features integrated needle positioning systems and modern digital parameter control panels to easily configure stitch cycles. [1, 2]

Are you looking to purchase the 4-thread (M1-424) or 5-thread (M1-534) variant, or do you need assistance troubleshooting a specific fault code on the control pane

High-Speed and Durable Performance

With a sewing speed of up to 6500 stitches per minute and 550 watts of power, the JIN M-1 Overlock Sewing Machine allows for rapid and reliable operation. It excels at tackling intensive sewing jobs with ease, making it suitable for commercial and industrial environments.

Versatile Stitching Capabilities

The JIN M-1 features a specialized DC 27 needle system and a robust mechanism involving the needle, upper looper, and lower looper. Its stitch length can be adjusted from 0.8 mm to 3.8 mm, and stitch width options include 4.0 mm and 6.0 mm, supporting a variety of seam types.

Efficient Fabric Handling

A bottom differential feed mechanism provides seamless fabric movement, minimizing puckering and distortion, even on challenging materials. This ensures excellent stitch quality and consistent results across multiple fabric types and thicknesses, ranging from 5 mm to 5.5 mm.

FAQ's of JIN M-1 OVERLOCK SEWING MACHINE:

Q: How do I use the JIN M-1 Overlock Sewing Machine for different fabrics?

A: The JIN M-1 is equipped with a bottom differential feed mechanism, making it suitable for a range of fabrics, from lightweight to thicker materials up to 5.5 mm. Adjust the stitch length and width, and set the appropriate tension to achieve optimal results for various fabric types.

Q: What warranty does the JIN M-1 Overlock Sewing Machine include?

A: The JIN M-1 comes with a warranty to ensure user peace of mind. For specific warranty terms and coverage information, you should refer to the supplier or manufacturer's warranty policy at the time of purchase.

Q: When is the best time to service the JIN M-1 Overlock Sewing Machine?

A: To maintain optimal performance, it is recommended to service the JIN M-1 regularly, especially if it is used extensively in commercial setups. Follow the service intervals suggested by your supplier or refer to the maintenance manual provided.

Q: Where can I purchase and receive after-sales support for the JIN M-1?

A: The JIN M-1 Overlock Sewing Machine is available in India through various importers, service providers, suppliers, and traders. Check with local authorized distributors for purchase, warranty, and service support.

Q: What is the process for adjusting stitch length and width on the JIN M-1?

A: To adjust the stitch length (from 0.8 mm to 3.8 mm) or width (4.0 mm or 6.0 mm), use the designated dials or levers on the machine's control panel. Refer to the user manual for step-by-step instructions specific to your sewing tasks.

Q: How does the machine handle thick materials during operation?

A: The JIN M-1 can sew materials up to 5.5 mm in thickness, utilizing its powerful 550-watt motor and stable feed mechanism to maintain even stitches and prevent material slippage or missed seams.

Q: What are the main benefits of using a bottom differential feed mechanism?

A: A bottom differential feed mechanism helps move fabric smoothly, preventing stretching or gathering and ensuring consistent stitching, especially when working with challenging or stretchy materials.
