JACK A2C SEWING MACHINE

Name: JACK A2C SEWING MACHINE
Brand: NEWTECH MACHINERY
Price: 25000.0 INR
Availability: InStock

Price 25000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

JACK A2C SEWING MACHINE Specification

Stitch width
0mm

Operate Method
Electric

Dimension (L*W*H)
64.5 cm x 24.8 cm x 55 cm. Centimeter (cm)

Product Type
JACK A2C SEWING MACHINE

Feed Mechanism
Bottom Feed (Drop Feed

Color
classic white finish with blue accents

Condition
New

Sewing Speed
5,000 stitches per minute

Warranty
1 year

Power
550w Watt (w)

Voltage
295v Volt (v)

Sewing Thickness
13mm

Stitch Formation
Single Needle Lockstitch

Needle
1

Stitch Length
5mm Millimeter (mm)

JACK A2C SEWING MACHINE Trade Information

Minimum Order Quantity
1 Number

Supply Ability
10 Per Month

Delivery Time
3 Days

About JACK A2C SEWING MACHINE

The

Jack A2C

is an industrial, single-needle lockstitch sewing machine designed for light to medium fabrics. It is widely recognized for its integrated automatic thread trimmer and energy-efficient direct-drive motor.

Key Features of the Jack A2C

Automatic Thread Trimmer: Increases productivity by automatically cutting the thread at the end of a seam, reducing manual labor.
Direct-Drive Motor: The motor is mounted directly on the main shaft, which leads to quieter operation, less vibration, and up to 70% energy savings compared to traditional clutch motors.
Safety Features: Includes high-voltage protection and an easy-to-use control panel for speed adjustment and needle positioning.
LED Lighting: Built-in LED lights illuminate the sewing area to reduce eye strain and improve accuracy.
Durability: Built with a heavy-duty frame suitable for long hours of industrial use.

Specifications

Max Speed: Up to 5,000 stitches per minute (SPM).
Stitch Length: Adjustable up to 5mm.
Presser Foot Lift: 5mm by hand or 13mm by knee lifter.
Lubrication: Automatic oiling system

The Jack A2C is primarily designed to handle a maximum material thickness of 10 mm

Thickness Capabilities by Model

While the series is versatile, your specific fabric capacity depends on the model variant:

Jack A2C-C (Standard)

: Optimized for light to medium-weight fabrics like shirts and standard denim.
Jack A2C-CH-7 (Heavy-Duty)
: Specifically designed for medium to heavy-weight materials. It features a larger stitch length (up to 7 mm) and uses heavier needles (DPx5) to pierce through thicker layers effectively.

Technical Factors for Sewing Thick Layers

Presser Foot Lift: The machine allows a manual lift of 5 mm and a knee-lifter height of up to 13 mm, which provides enough clearance to position thick materials like multi-layered denim or canvas.
Needle Penetration: It uses a high-torque motor (5.5 NM) and "FST" technology, which provides enough force to pierce approximately 100 layers of paper without losing speed.
Needle Sizes: To sew thicker fabrics safely, you should use the upper range of compatible needles, such as Size 18 (#110
