Jack F6 single-needle lockstitch sewing machine

Price 24000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Jack F6 single-needle lockstitch sewing machine Specification

Stitch Formation
single-needle lockstitch formation.

Sewing Thickness
13mm

Dimension (L*W*H)
645*248*550 Millimeter (mm)

Warranty
1 year

Product Type
Jack F6 single-needle lockstitch sewing machine

Color
White/Blue

Power
550 Watt (w)

Needle
1

Sewing Speed
5,000 stitches per minute

Stitch width
0

Operate Method
Electric

Voltage
220 Volt (v)

Condition
New

Feed Mechanism
drop-feed mechanism

Stitch Length
7mm Millimeter (mm)

Jack F6 single-needle lockstitch sewing machine Trade Information

Minimum Order Quantity
1 Number

Delivery Time
4 Days

About Jack F6 single-needle lockstitch sewing machine

The Jack F6 is an industrial-grade, single-needle lockstitch sewing machine designed for high-speed production with a focus on energy efficiency. It is an evolution of the popular Jack F5 model, offering enhanced power and improved handling for heavier fabrics.

Key Features

Energy Efficiency: Features an integrated direct-drive servo motor that significantly reduces power consumption compared to traditional clutch motors and operates silently.
High-Speed Performance: Capable of reaching speeds up to 5,000 stitches per minute for medium-weight fabrics, or 3,500 RPM for the heavy-duty HL version.
Enhanced Thickness Handling: Provides a 7% improvement in thickness handling over previous models, allowing it to sew through up to 15 layers of denim reliably.
User Comfort & Safety: Includes an integrated LED work light, a point-to-point button for precise stitching, and a safety switch that displays an error if the machine is powered on accidentally.
Durability: Built with a heavy-duty cast metal body and an automatic lubrication system to extend the machine's lifespan during long production hours.

The Jack F6 is engineered to handle significant material thickness, notably sewing up to 15 layers of denim smoothly. This capability is a core feature of its design, marketed as a 7% improvement in thickness handling over previous models like the Jack F5. Material Capacity by Model While all Jack F6 machines have robust penetration power, specific versions are optimized for different thickness levels:

Maximum Sewing Thickness: The machine can handle materials up to approximately 13mm in total thickness, matching its maximum presser foot lift height.
Presser Foot Lift: The presser foot can be raised between 5mm and 13mm, providing ample clearance for sliding thick or multi-layered sections under the needle.
Needle Penetration: The integrated direct-drive motor provides high torque, ensuring the needle can penetrate dense fabrics

Main Body: The machine features a clean, industrial White or off-white finish.
Accent Colour: Most retailers specify a White/Blue combination, with blue typically found on the logo, control panel details, or decorative elements.
Tech Appearance: It has a modern "tech" look that uses UV printing for certain coloured details on the machine head.

Availability & Listings

Flipkart: Lists the model specifically in White.
Amazon India: Displays a Blue variant, though descriptions often refer to the standard White/Blue industrial aesthetic.
Alraee Sewing Store: Confirms the primary color scheme as White Blue While the Jack F6 is most common in white/blue, other Jack models (like the A6F) are marketed with more varied color options. For the F6 , the classic industrial white is the standard to ensure a clean look in professional workshops.

The Jack F6 uses a standard drop-feed mechanism, which is the most common system for industrial lockstitch machines.

How the Drop-Feed System Works

Bottom-Feed Teeth: The mechanism relies on feed dogs (small metal teeth) located below the needle plate.
Cyclic Movement: These teeth move in a rectangular motionrising up to grip the fabric against the presser foot, moving backward to advance the material by one stitch length, and then dropping down to return to the starting position.
Medium-Weight Optimization: The F6's feed is specifically tuned for medium-weight fabrics, ensuring stable and consistent feeding even at high speeds of up to 5,000 RPM.

Rotary Hook System: The stitch is formed using a high-speed rotary hook that catches the needle thread loop and carries it around the bobbin case to create the lock.
Thread Type: It uses two threads (needle and bobbin) to complete the lockstitch.
Automatic Lubrication: An integrated oil pump ensures the moving parts of the stitch-forming mechanism remain lubricated for smooth operation even at 5,000 RPM.

Stitch Control Features

Stitch Length: The stitch length is adjustable up to 5 mm on the standard model and up to 7 mm on the heavy-duty HL-7 version.
Precision Positioning: A point-to-point button allows for a single half-stitch to be added manually, which is critical for turning corners or precision finishing.
Needle Positioning: The electronic control system allows you to set the needle to stop either consistently up or down after a seam, facilitating easy fabric pivoting.
Thread Trimming: Depending on the specific regional version, the F6 may include an automatic thread trimmer to cut thread tails at the end of a seam, though some versions are listed as "non-trim" model Performance in Thick Materials

The stitch formation remains stable across a variety of fabrics thanks to a 7% improvement in thickness handling over the previous F5 model. It is capable of maintaining consistent stitch quality through up to 15 layers of denim

For a visual demonstration of the stitch quality and how it handles different fabric thicknesses:
